Vestil AIR-THL Air Corner Tilter – Ergonomic Pneumatic Box and Crate Tilter for Bulk Containers

Features

• Model: Vestil AIR-THL

• Multi-ply airbag provides smooth pneumatic lift and tilt

• Ideal box tilter and crate tilter for ergonomic unloading

• Hand lever air corner tilter with optional foot treadle operation

• Factory-set regulator activates tilt at 900 lbs (adjustable)

• 45° maximum tilt angle shifts contents to one corner

• Comes with adjustable 12” wand holder (3.5” inner diameter)

Specifications

Boost productivity and reduce strain in material handling with the Vestil AIR-THL Air Corner Tilter, a pneumatic, floor-level solution designed to simplify the loading and unloading of bulk containers, crates, and gaylords. This air-powered corner tilter uses a durable, multi-ply airbag to safely and efficiently shift product contents to one corner of the container—making it easy to remove materials manually or mechanically.

The AIR-THL is accessible by both pallet jacks and forklifts, and is operated using a hand lever control or optional foot treadle for hands-free use. A factory-set adjustable air regulator begins tilting automatically when the load reaches approximately 900 lbs, ensuring ergonomic efficiency and consistent performance. This air tilter also includes a height-adjustable vacuum pick-up wand holder (3-1/2″ ID) with 12″ of vertical travel to suit different container sizes.
